Achieve cost-effectiveness with small footprint with the FHS Series
Ultra-Compact Design: One of the smallest integrated current sensors on the market, perfect for space-constrained applications such as power supplies and PCB layouts.
High Precision for Low Currents: Engineered for accurate current measurement with a nominal value of 2 A, ensuring reliable performance in sensitive applications.
Easy PCB Integration: Features a surface-mount design, making it easy to incorporate directly into your existing PCB layout without requiring additional mounting hardware.
Low Insertion Loss: Minimal impact on the overall system performance, providing accurate current sensing without significant power loss
Key Features of the FHS Series
Advanced Hall Effect Technology with Integrated Magnetic Concentrator: Enhanced measurement accuracy in compact applications.
Magnetic Field Measurement Range of ±3.3 mT: Providing reliable current sensing for low-current applications.
High Bandwidth of 160kHz: Offers rapid response and accurate real-time current monitoring, ideal for dynamic and high-frequency applications.
Low Power Consumption: Designed to minimize power usage, making it suitable for energy-efficient and battery-operated systems.
Wide Operating Temperature Range: Performs reliably in extreme environments, from -40°C to +125°C.
Engineered for a Wide Range of Applications
Industrial Automation: Delivering precise monitoring for better system performance in control systems, motors drives, and industrial equipment.
Power Supplies & Converters: Enhance efficiency and stability in DC/DC converters and power modules.
Battery Management Systems (BMS): Reliable current sensing for effective battery monitoring and protection.
HVAC Systems: Helping to optimize energy usage and maintain performance in heating, ventilation and air conditioning applications.
FHS AH AT A GLANCE
| Product | Order | Nominal sensitivity [mV/A] | Sensitivity range | Magnetic field measurement range | Supply Voltage [Uc] | Bandwidth | Temp. range [°C] |
|---|---|---|---|---|---|---|---|
| FHS AH 600 | 600 | 200 mV/A | ±3.3 | 5V | 160 KHz | -40 to 125°C |
Start your journey with LEM
Get in touch for more technical details or request a detailed quote tailored to your project needs.
Why LEM?
LEM is a global leader in electrical measurement solutions, providing innovative and high-quality sensors for automotive, renewable energy, and industrial applications. With a commitment to performance and reliability, we are your trusted partner for integrated current sensing solutions.
Global Leader in Sensing Technology: With over 50 years of experience, LEM sets the standard in current and voltage sensing.
Quality You Can Rely On: Built to meet the highest industry standards, providing accurate and reliable measurements.
Expert Support: Our team of specialists is here to help you find the right solution for your unique requirements.
