AP
AC Current range from 10A to 400A selectable by a switch.,RMS version. Several types of output: 4-20mA, 0-5V or 0-10V selectable by a switch. PRiME (Rogowski) technology. Wide bandwidth up to 6 kHz. Split core
Model details
AP 200 B10
AC Current range 100, 150 & 200A selectable by a switch, RMS version, Voltage output: 0-5 or 0-10 V DC selectable by a switch, Bandwidth 30-2000Hz, Split core with a 18 mm diameter aperture
- Series
-
AP
- Measurement
-
Current
- Nominal Value
-
100 A, 150 A, 200 A
- Measuring Range
-
200 A
- Second. Nominal Signal
-
Voltage
- Second. Nominal Signal Value
- DC RMS 0-5V
- Primary Signal
-
AC
- Supply Voltage
-
External DC Unipolar
- Supply Voltage Range
- 24 - 24 V
- Accuracy
- 1 %
- Op. Temperature
- -20 °C / 60 °C
- Technology
-
Prime
- Mounting
-
DIN railPanel
- Applications
-
AutomationSmart Grid
FRONT
BACK
LEFT
RIGHT
